Portable Hydraulic Power Unit

|
|
|
|
|
|
|
|
|
|
|
Consisting of 120 gallon reservoir, Young heat exchanger Denison 20 GPM, 3000-5000 PSI pump, recirculating pump-motor unit "in tank style discharge pulsation damping accumulator, rivett relief valve…relief valve, electric vent for remote control. "In tank" high-low automotive shut down, "in tank" fluid temperature sensor by Fenewal.
Pump is variable volume pressure compensated and mounted to a 40 HP, 1180 RPM motor, 3 PH, 60 cycles.
Entire unit is mounted on casters with JIC style reservoir, removable end cover for clear out and inspection on both ends.
Motor
Manufactured: Ajax
Part No: AM-40T200
HP: 40
RPM: 1180
Vac: 230/460
PH: 3
HZ: 60
Frame: 364T
Rivett valve, part ?: P3119-06-3011
MTS Accumulator 12.5-30-90, size 1 pint
Double A, model QJ-005-C-10B1
Heat exchange 36" x 6"
Filters "Schoeder" 3000 PSI, 1 DF-30-1CC10-P-D Ele. CC10, 1 TF-1-1A10-P-N Ele. A25
|
|
|
|
|
|
Units
Subject To Prior Sale
